Full Height Turnstile (Double)

Details

FTD100 series full height turnstiles (double pass) are an ideal solution for pedestrian crossings that do not have security guards and require high security. It is designed to allow only 1 person to pass through each passage. Transition is provided with 3-arm (120 degree) triangular rotor or 4-arm (90 degree) square rotor options.

Main factors such as modern microelectronic card, mechanism processed on CNC machines, non-contact position sensor technology, adjustable damping ratio with hydraulic damper, automatic centering with cam mechanism and coating of the mechanism against rust ensure that F100 series turnstiles operate problem-free for many years. Additionally, there is a standard ceiling lamp at the top of the turnstile for dark environments.

SKU: MPRGATE - FTD100 Category:
Weight (approx.)600kg
environmental resistanceStainless steel, powder coated (optional)
StructureDesigned for severe conditions
SteelSS304
Power requirement220 Volt, 1 Phase, 50-60 Hz
In case of power outagePassage is free or passage is locked
ButtonOpen direction A, open direction B
Extra I/O in PLCDesired features can be added later
backup power supplyUPS (optional)
environmental conditions-25 °C and +65 °C, 95% humidity
